Star Trac Treadmill 7600 Pro AC Motor Overlay Keypad

Star Trac Pro 7600 Treadmill AC Motor Keypad Overlay (Non OEM). includes Electronic Membrane and is a direct replacement for the 7600 AC Motor Star Trac Treadmill model. A cost effective solution of replacing the Overlay and Keypad only (the parts that fail) rather than the additional plastic facia.

Engineers Note:
You should remove the Centre Console Facia from the Treadmill by removing the rear cover screws. Gently warm the old/faulty Keypad and slowly peel it away from the plastic facia. With the old keypad/membrane removed, ensure that the plastic plate is clean of any debris and adhesive, carefully feed the electronic connector tail through the lower slot and then slowly lower and apply the new Keypad/membrane onto the facia plate working from one side to the other or from top to bottom which ever you feel confident, ensuring there is proper contact and no trapped air between the adhesive backing of the Keypad and the surface of the facia plate.

For Further advice please telephone our Service Dept on 01656 729846

OEM Ref: P037153590

Availability: 3 – 4 Working Days

Part Number: 7-0043
